Ball float Steam Trap Manufacturer in India

Category: Business

Specialityvalve is a leading and most trusted Ball float steam trap manufacturer in India. A Ball float steam trap is a type of mechanical steam trap which relies on the difference in density between steam and condensate in order to operate. These steam traps can pass massive amounts of condensate and are suitable for a wide range of process applications. Working Principle: By detecting the difference in density between steam and condensate, the ball float type trap works. Condensate entering the trap will raise the ball float, which will then pull the valve off its seat and release condensate. Early traps of this type were vented via a manually driven cock at the top of the body since, as can be seen, the valve is always flooded and neither steam nor air will travel through it. Utilizing a thermostatic air vent are modern traps. As the trap manages condensation, this enables the original air to pass. The thermostatic steam trap and automatic air vent share a balanced pressure capsule element and are both situated in the steam space above the condensate level. When the first air is released, it closes and doesn't open again unless air or other non-condensable gases build up during regular operation and lower the temperature of the air/steam mixture. An additional advantage of the thermostatic air vent is that it considerably boosts condensate capacity during cold start-up. In the past, if waterhammer was present in the system, the thermostatic air vent was a weak spot. If the waterhammer was particularly strong, the ball might even be harmed. Modern float traps, on the other hand, have an air vent that is small, incredibly durable, and made entirely of stainless steel. This, combined with the ball's modern welding, makes the entire float-thermostatic steam trap incredibly durable and dependable in waterhammer circumstances. The float-thermostatic trap comes the closest to an ideal steam trap in many areas. Regardless of fluctuations in steam pressure, it will release condensate as soon as it forms. Advantages of ball float steam trap: • These are resistant to water hammers. • Ball float steam traps can handle light and heavy condensate loads without getting affected by fluctuations in pressure rate or flow. • Ball float steam traps have a variety of applications. Applications of Ball float steam trap : • Ball float steam traps are used in heating ovens. • They are used in drying cylinders. • Ball float steam traps are used in separator drainages. Description: • Body material: Carbon steel, cast steel (WCB, WCC, LCC, WC6, LCB, WC9), stainless steel (SS316, SS304, CF8), ductile iron. • Class: 150 to 2500. • Size: ¾” – 4”. • Ends: Socket weld butt weld, flanged, threaded. Visit: https://www.specialityvalve.com/product-category/ball-float-steam-trap/ Thermostatic Steam Trap Manufacturer in India Specialityvalve is a well reputed Thermostatic steam trap manufacturer in India. Thermostatic Steam Traps rely on the temperature differential between steam and condensate to function. The temperature of the condensate is lower than that of the steam. Thermostatic steam traps have a port that opens or closes based on the inlet fluid's temperature. Steam traps are automatic valves that filter out condensate and non-condensable gases like air while enabling steam to flow at a steady rate. It's most commonly used as a source of heat or mechanical power. Operating principle of a thermostatic steam trap: The trap is entirely open when it first starts up, removing the air and releasing the condensate. The evaporation of the liquid inside the thermostatic capsule membrane causes a pressure differential, causing the aperture to close when the temperature reaches the saturated steam level proportional to the pressure. The liquid condenses when the condensate cools, lowering the membrane's internal pressure. The resulting pressure differential will encourage external pressure acting on the membrane to retract and open the aperture, allowing condensate to discharge, and the cycle will repeat. Advantages: 1. Highest Efficiency 2. Simple to Maintain 3. Simple to Install 4. Air or other gaseous discharge Thermostatic Steam Traps are used: 1. Petrochemical Industry 2. Hydro power plants 3. Chemical Industry Available Material: Ductile iron, Cast Iron, Carbon Steel, Cast steel (WCB, WCC, WC6, WC9, LCC, LCB), Stainless Steel (SS316, SS304, CF8). Size: 1/4” – 2”. Class: 150 to 1500. Ends: Socket weld butt weld, flanged, threaded. https://www.specialityvalve.com/product-category/thermostatic-steam-trap/
